Solar Charge Controller
SolarEpic is a professional seller of solar products. Provide quality solar controllers and accessories.
Our solar charger controller is super easy to install munuall without any prifessional help.No tricks,hacks or complicated tools are needed to install it.It features two pre drilled holes for convenient setup.Just attach it to a surfackeusing drills and its ready for use!
Key features that you need to look out for:
- It is a true MPPT Controller which will deliver 99% efficiency
- Can be used for over-paneling (which means you can add more panels than what it is rated for). This feature is very hard to find, but present in all of the controllers that I recommend
- Temperature Compensation- This increases the life of your batteries
- Manual charge profiles (charge any type of battery): Only for advanced users. This will allow you to fine tune your charge profile to a specific battery
- Large and strong input terminal that can accommodate large wire gauges (very hard to find)
Featured Products
This combination include following items：
EPEVER Tracer BN MPPT Solar Charge Controller
Based on common negative design and advanced MPPT control algorithm
MPPT Charge efficiency > 99%
This unit is compatible with Tracer A(N) , TRIRON N, Tracer BN, VSxxxxBN series controllers ONLY from EPsolar. And it's NOT compatible with RN series MPPT charge controller. Description MT-50, a new-generation remote display for EPEVER MPPT controllers is an associated display device which supports both the latest communication protocol and the voltage technology standard of mppt solar controllers.
Battery Temperature Sensor&Monitoring adapter
Remote Temperature Sensor
Model: RTS300R47K3.81A
Acquisition of battery temperature for undertaking
temperature compensation of control parameters
Length: 3 M
USB to RS485 Converter Adapter
Model: CC-USB-RS485-150U
SolarEpic Tracer4215BN 40amp Solar Charge Controller Feature:
- Negative Grounding, 150V /138V PV Input
- Metal Case allows for natural heat dissipation
- Support 4 charging options: Sealed, Gel, Flooded and User
- 4 Stage Charging
- Serial connection (string) of PV modules allows minimize the charging current as a way of saving the energy
- Advanced Maximum Power Point Tracking (MPPT) technology, with efficiency no less than 99.5%
- Ultra-fast tracking speed and tracking efficiency
- Features Standard Modbus Interface with RS485 Port
MPPT Solar Charge Controller 40A Tracer4215BN Schematic Diagram
|
|
|
|
|---|---|---|
SolarEpic 4215BN Solar Charge Controller 40A:Built with advanced power tracking technology to optimize the working of your solar charger system. The controller features a smart tracking algorithm that maximizes the energy from the solar PV module(s) and charge the battery. It supports over four charging options: sealed, gel, flooded and user-defined. Battery parameters can be set using the attached MT50 remote meter. |
MT50 Remote Meter:Wide LED screen displays the real time operational data and the working status in digital, graphic and textual forms. Basically used for monitoring and setting the controller, it automatically identifies the type, model and relevant parameter data of solar controllers. |
Battery Temperature Sensor and PC Communication Cable:It is used to monitor each controller on the network using Solar Station PC software and update the firmware. Measures 3m and works great for Tracer BN/A series MPPT charge controller. The connectors are well made to secure the connection. |
VIDEO DEMO
Latest product information（For more product video please click here）
This combination include following items：
EPEVER Tracer AN MPPT Solar Charge Controller
Based on common negative design and advanced MPPT control algorithm
MPPT Charge efficiency > 99%
This unit is compatible with Tracer A(N) , TRIRON N, Tracer BN, VSxxxxBN series controllers ONLY from EPsolar. And it's NOT compatible with RN series MPPT charge controller. Description MT-50, a new-generation remote display for EPEVER MPPT controllers is an associated display device which supports both the latest communication protocol and the voltage technology standard of mppt solar controllers.
Battery Temperature Sensor&Monitoring adapter
Remote Temperature Sensor
Model: RTS300R47K3.81A
Acquisition of battery temperature for undertaking
temperature compensation of control parameters
Length: 3 M
USB to RS485 Converter Adapter
Model: CC-USB-RS485-150U
- 12 / 24VDC automatically identifying system voltage
- Rated charge current: 40A
- Max Input Power: 12V @ 520W | 24V @ 1040W
- Max PV open circuit voltage:100VDC (92V at 25℃ temperature)
- Battery type selection: lead-acid (Gel, Sealed, Flooded) and Lithium
- Charging Power and Current Limitation Function
- User programmable for battery types, load control etc.
- Accurately recognizing and tracking of multiple power point
- PV short circuit / PV reverse polarity /Battery over voltage /Battery over discharge / Battery reverse polarity / Load overload protection
Warm tips：
Step: Connect the system in the order of 1.battery-->2. load-->3.PV array, and disconnect the system in the reverse order 3. 2. 1.
- NEVER connect the soalr panel array to the controller Without/Before a Battery.
- Battery must be connected FIRST !!!
- DO NOT connect any inverter/ wind/Alternator or Charger into the charge controller!
- If the remote temperature sensor is not connected to the controller,, the default setting for battery charging or discharging temperature is 25 °C without temperature compensation.
- The wire size is only for reference. If there is a long distance between the PV array and the controller or between the controller and the battery, larger wires can be used to reduce the voltage drop and improve performance.
How to program for Lithium Battery？
1. Via PC (Accessories needed：RS485),
2. Via phone APP (Accessories needed：Ebox-Wifi or Ebox-Blue)
Software download website: EPever official website or look for in the manual
VIDEO DEMO
Latest product information（For more product video please click here）
This combination include following items：
EPEVER Tracer AN MPPT Solar Charge Controller
Based on common negative design and advanced MPPT control algorithm
MPPT Charge efficiency > 99%
This unit is compatible with Tracer A(N) , TRIRON N, Tracer BN, VSxxxxBN series controllers ONLY from EPsolar. And it's NOT compatible with RN series MPPT charge controller. Description MT-50, a new-generation remote display for EPEVER MPPT controllers is an associated display device which supports both the latest communication protocol and the voltage technology standard of mppt solar controllers.
Battery Temperature Sensor&Monitoring adapter
Remote Temperature Sensor
Model: RTS300R47K3.81A
Acquisition of battery temperature for undertaking
temperature compensation of control parameters
Length: 3 M
USB to RS485 Converter Adapter
Model: CC-USB-RS485-150U
Warm tips
Step Always connect the battery before connect the solar panel,disconnect in the reverse order.
Step: Connect the system in the order of 1. battery--> 2. load-->3. PV array, and disconnect the system in the reverse order 3. 2. 1.
- Battery must be connected first !!!
- Never connect the soalr panel array to the controller Without / Before a Battery.
- DO NOT connect any inverter/ wind/Alternator or Charger into the charge controller!
- If the remote temperature sensor is not connected to the controller, the default setting for battery charging or discharging temperature is 25 °C without temperature compensation.
- The wire size is only for reference. If there is a long distance between the PV array and the controller or between the controller and the battery, larger wires can be used to reduce the voltage drop and improve performance.
MT50 Remote Meter:
- Compatible with EPever Tracer-A/AN/BN, LS-B/BP, VS-BN series controllers
- With attached extension cable, it will showing the operational data and working status of connected MPPT charge controller.
RS485-150U Cable(1.5m):
- used to monitor each controller on the network using Solar Station PC software and update the firmware.
Remote Temperature Sensor（TS-R，3m）：
- Obtain battery temperature for temperature compensation of control parameters
|
Tracer 5415AN MPPT Charge Controller 50 amp12V / 24V / 36V/ 48V DC Auto Rated charge current: 50 amp Max Input Power: 625W-2500W ( 625W/12V battery 1250W/ 24V battery 1875W/ 36V battery 2500W/ 48V battery) Max.PV open circuit voltage: 150VDC (138V at 25℃ temperature) Battery type selection: lead-acid ( Gel, Sealed ) Flooded batteries and User Common-Negatived Ground Controller Battery Input:8V～68V User programmable for battery types, load control etc. Termina: 6AWG/16mm2 Recommended cable: 6AWG/16mm2 |
VIDEO DEMO
Latest product information（For more product video please click here）
SolarEpic MT50 LCD Remote Meter Suitable For Tracer-AN/Tracer-BN Charge Controller Epever
Note : This kind of meter just can be use for epever controller,can't be use for
renogy or hqst controller.
Features:
data of controllers;
■ Real-time display the operational data and working status of the connection devices in digital, graphic and textual forms by a large-screen multifunction LCD;
■ Direct, convenient and rapid operation of six navigation function keys;
■ Both data and power flowing on the same lead, no need for external power;
■ Real-time data monitoring and remote load switchover of the controllers, and data browse and modification of device parameters, charge control parameters and load control parameters;
■ Real-time display and acoustic alarm of failure information of the connection devices;
■ Longer communication distance based on RS485.
Electrical Parameters
|
Faceplate dimensions |
98×98 mm |
|
Frame dimensions |
114×114 mm |
|
Connector type |
RJ45 |
|
Meter cable |
Standard 2m,Max 50 m |
|
Meter weight |
Simple package: 0.23 Kg Standard package:0.32 Kg |
|
Ambient temperature |
-20℃~+70℃ |
20A EPEVER Tracer 2206AN MPPT Solar Charge Controller
Based on common negative design and advanced MPPT control algorithm
MPPT Charge efficiency > 99%
Technical Data: Nominal system voltage:12/24VDC auto work
Rated charge current :20A
Rated discharge current: 20A
Battery input voltage range: 8-32V
Max. PV open circuit voltage:60V(at minimum operating environment temperature) 46V(at 25℃ environment temperature)
MPP voltage range:V(BAT)+2V～72V
Max. PV input power:260W(12V Battery) & 520W(24V battery)
Power terminals:#12 AWG(4mm2)
MT50 Remote Meter
This unit is compatible with Tracer A(N) , TRIRON N, Tracer BN, VSxxxxBN series controllers ONLY from EPsolar. And it's NOT compatible with RN series MPPT charge controller. Description MT-50, a new-generation remote display for EPEVER MPPT controllers is an associated display device which supports both the latest communication protocol and the voltage technology standard of mppt solar controllers.
Technical Data Faceplate dimension:98×98 mm / 3.86×3.86 inch Frame dimension:114×114 mm / 4.49×4.49 inch Connector type: RJ45 Meter cable:Standard 2m,Max 50m Ambient Temperature: -20°C -- +70°C/-4°F -- 158°F
SolarEpic 2206AN Solar Charge Controller 20A:
The controller adopts the three-stage charging mode, and
has perfect electronic protection function, which can
effectively extend the battery life, improve the system
performance, and ensure the system safety, stability and
long-term operation. TRIRION controller can be widely used
in RV, telecommunication base station, household system,
field monitoring, etc.
Product Features
• Advanced MPPT technology, with efficiency no less than 99.5%
• Monitor and set the parameters via mobile phone APP or PC software
• Advanced MPPT control algorithm to minimize the maximum power point loss rate and loss time
• Wide MPP operating voltage range
• High quality components, perfecting system performance, with maximum conversion efficiency of 98%
•Accurate recognition and tracking of multiple-peaks maximum power point
• International famous brands of ST and IR's components of high quality and low failure rate are used, which can ensure the product’s service life
• Charging power and current limitation function
• Compatible with lead-acid and lithium-ion batteries
Maximum Power Point Tracking Technology
Due to the nonlinear characteristics of solar array, there is a maximum energy output point (Max Power Point) on its curve. Traditional controllers, with switch charging technology and PWM charging technology, can’t charge the battery at the maximum power point, so can’t harvest the maximum energy available from PV array, but the solar charge controller with Maximum Power Point Tracking (MPPT) Technology can lock on the point to harvest the maximum energy and deliver it to the battery
The MPPT algorithm of our company continuously compares and adjusts the operating points to attempt to locate the maximum power point of the array. The tracking process is fully automatic and does not need user adjustment.
As the Figure 1-2, the curve is also the characteristic curve of the array, the MPPT technology will ‘boost’ the battery charge current through tracking the MPP. Assuming 100% conversion efficiency of the solar system, in that way, the following formula is established:
Product information
|
Item |
Tracer1206AN Tracer1210AN |
Tracer2206AN Tracer2210AN |
Tracer3210AN |
Tracer4210AN |
|||
|
Dimension |
172x139 x 44mm |
220x154x 52mm |
228x164x55mm |
252x180x63mm |
|||
|
Mounting dimension |
130x130mm |
170x145mm |
170x164mm |
210x171mm |
|||
|
Mounting hole size |
Φ5mm |
||||||
|
Terminal |
12AWG(4mm2) |
6AWG(16mm2) |
6AWG(16mm2) |
6AWG(16mm2) |
|||
|
Recommended cable |
12AWG(4mm2) |
10AWG(6mm2) |
8AWG(10mm2) |
6AWG(16mm2) |
|||
|
Weight |
0.57kg |
0.94kg |
1.26kg |
1.65kg |
|||
The Collection
This combination include following items：
EPEVER Tracer BN MPPT Solar Charge Controller
Based on common negative design and advanced MPPT control algorithm
MPPT Charge efficiency > 99%
This unit is compatible with Tracer A(N) , TRIRON N, Tracer BN, VSxxxxBN series controllers ONLY from EPsolar. And it's NOT compatible with RN series MPPT charge controller. Description MT-50, a new-generation remote display for EPEVER MPPT controllers is an associated display device which supports both the latest communication protocol and the voltage technology standard of mppt solar controllers.
Battery Temperature Sensor&Monitoring adapter
Remote Temperature Sensor
Model: RTS300R47K3.81A
Acquisition of battery temperature for undertaking
temperature compensation of control parameters
Length: 3 M
USB to RS485 Converter Adapter
Model: CC-USB-RS485-150U
SolarEpic Tracer4215BN 40amp Solar Charge Controller Feature:
- Negative Grounding, 150V /138V PV Input
- Metal Case allows for natural heat dissipation
- Support 4 charging options: Sealed, Gel, Flooded and User
- 4 Stage Charging
- Serial connection (string) of PV modules allows minimize the charging current as a way of saving the energy
- Advanced Maximum Power Point Tracking (MPPT) technology, with efficiency no less than 99.5%
- Ultra-fast tracking speed and tracking efficiency
- Features Standard Modbus Interface with RS485 Port
MPPT Solar Charge Controller 40A Tracer4215BN Schematic Diagram
|
|
|
|
|---|---|---|
SolarEpic 4215BN Solar Charge Controller 40A:Built with advanced power tracking technology to optimize the working of your solar charger system. The controller features a smart tracking algorithm that maximizes the energy from the solar PV module(s) and charge the battery. It supports over four charging options: sealed, gel, flooded and user-defined. Battery parameters can be set using the attached MT50 remote meter. |
MT50 Remote Meter:Wide LED screen displays the real time operational data and the working status in digital, graphic and textual forms. Basically used for monitoring and setting the controller, it automatically identifies the type, model and relevant parameter data of solar controllers. |
Battery Temperature Sensor and PC Communication Cable:It is used to monitor each controller on the network using Solar Station PC software and update the firmware. Measures 3m and works great for Tracer BN/A series MPPT charge controller. The connectors are well made to secure the connection. |
VIDEO DEMO
Latest product information（For more product video please click here）
This combination include following items：
EPEVER Tracer AN MPPT Solar Charge Controller
Based on common negative design and advanced MPPT control algorithm
MPPT Charge efficiency > 99%
This unit is compatible with Tracer A(N) , TRIRON N, Tracer BN, VSxxxxBN series controllers ONLY from EPsolar. And it's NOT compatible with RN series MPPT charge controller. Description MT-50, a new-generation remote display for EPEVER MPPT controllers is an associated display device which supports both the latest communication protocol and the voltage technology standard of mppt solar controllers.
Battery Temperature Sensor&Monitoring adapter
Remote Temperature Sensor
Model: RTS300R47K3.81A
Acquisition of battery temperature for undertaking
temperature compensation of control parameters
Length: 3 M
USB to RS485 Converter Adapter
Model: CC-USB-RS485-150U
- 12 / 24VDC automatically identifying system voltage
- Rated charge current: 40A
- Max Input Power: 12V @ 520W | 24V @ 1040W
- Max PV open circuit voltage:100VDC (92V at 25℃ temperature)
- Battery type selection: lead-acid (Gel, Sealed, Flooded) and Lithium
- Charging Power and Current Limitation Function
- User programmable for battery types, load control etc.
- Accurately recognizing and tracking of multiple power point
- PV short circuit / PV reverse polarity /Battery over voltage /Battery over discharge / Battery reverse polarity / Load overload protection
Warm tips：
Step: Connect the system in the order of 1.battery-->2. load-->3.PV array, and disconnect the system in the reverse order 3. 2. 1.
- NEVER connect the soalr panel array to the controller Without/Before a Battery.
- Battery must be connected FIRST !!!
- DO NOT connect any inverter/ wind/Alternator or Charger into the charge controller!
- If the remote temperature sensor is not connected to the controller,, the default setting for battery charging or discharging temperature is 25 °C without temperature compensation.
- The wire size is only for reference. If there is a long distance between the PV array and the controller or between the controller and the battery, larger wires can be used to reduce the voltage drop and improve performance.
How to program for Lithium Battery？
1. Via PC (Accessories needed：RS485),
2. Via phone APP (Accessories needed：Ebox-Wifi or Ebox-Blue)
Software download website: EPever official website or look for in the manual
VIDEO DEMO
Latest product information（For more product video please click here）
This combination include following items：
EPEVER Tracer AN MPPT Solar Charge Controller
Based on common negative design and advanced MPPT control algorithm
MPPT Charge efficiency > 99%
This unit is compatible with Tracer A(N) , TRIRON N, Tracer BN, VSxxxxBN series controllers ONLY from EPsolar. And it's NOT compatible with RN series MPPT charge controller. Description MT-50, a new-generation remote display for EPEVER MPPT controllers is an associated display device which supports both the latest communication protocol and the voltage technology standard of mppt solar controllers.
Battery Temperature Sensor&Monitoring adapter
Remote Temperature Sensor
Model: RTS300R47K3.81A
Acquisition of battery temperature for undertaking
temperature compensation of control parameters
Length: 3 M
USB to RS485 Converter Adapter
Model: CC-USB-RS485-150U
Warm tips
Step Always connect the battery before connect the solar panel,disconnect in the reverse order.
Step: Connect the system in the order of 1. battery--> 2. load-->3. PV array, and disconnect the system in the reverse order 3. 2. 1.
- Battery must be connected first !!!
- Never connect the soalr panel array to the controller Without / Before a Battery.
- DO NOT connect any inverter/ wind/Alternator or Charger into the charge controller!
- If the remote temperature sensor is not connected to the controller, the default setting for battery charging or discharging temperature is 25 °C without temperature compensation.
- The wire size is only for reference. If there is a long distance between the PV array and the controller or between the controller and the battery, larger wires can be used to reduce the voltage drop and improve performance.
MT50 Remote Meter:
- Compatible with EPever Tracer-A/AN/BN, LS-B/BP, VS-BN series controllers
- With attached extension cable, it will showing the operational data and working status of connected MPPT charge controller.
RS485-150U Cable(1.5m):
- used to monitor each controller on the network using Solar Station PC software and update the firmware.
Remote Temperature Sensor（TS-R，3m）：
- Obtain battery temperature for temperature compensation of control parameters
|
|
Tracer 5415AN MPPT Charge Controller 50 amp12V / 24V / 36V/ 48V DC Auto Rated charge current: 50 amp Max Input Power: 625W-2500W ( 625W/12V battery 1250W/ 24V battery 1875W/ 36V battery 2500W/ 48V battery) Max.PV open circuit voltage: 150VDC (138V at 25℃ temperature) Battery type selection: lead-acid ( Gel, Sealed ) Flooded batteries and User Common-Negatived Ground Controller Battery Input:8V～68V User programmable for battery types, load control etc. Termina: 6AWG/16mm2 Recommended cable: 6AWG/16mm2 |
VIDEO DEMO
Latest product information（For more product video please click here）
SolarEpic MT50 LCD Remote Meter Suitable For Tracer-AN/Tracer-BN Charge Controller Epever
Note : This kind of meter just can be use for epever controller,can't be use for
renogy or hqst controller.
Features:
data of controllers;
■ Real-time display the operational data and working status of the connection devices in digital, graphic and textual forms by a large-screen multifunction LCD;
■ Direct, convenient and rapid operation of six navigation function keys;
■ Both data and power flowing on the same lead, no need for external power;
■ Real-time data monitoring and remote load switchover of the controllers, and data browse and modification of device parameters, charge control parameters and load control parameters;
■ Real-time display and acoustic alarm of failure information of the connection devices;
■ Longer communication distance based on RS485.
Electrical Parameters
|
Faceplate dimensions |
98×98 mm |
|
Frame dimensions |
114×114 mm |
|
Connector type |
RJ45 |
|
Meter cable |
Standard 2m,Max 50 m |
|
Meter weight |
Simple package: 0.23 Kg Standard package:0.32 Kg |
|
Ambient temperature |
-20℃~+70℃ |
20A EPEVER Tracer 2206AN MPPT Solar Charge Controller
Based on common negative design and advanced MPPT control algorithm
MPPT Charge efficiency > 99%
Technical Data: Nominal system voltage:12/24VDC auto work
Rated charge current :20A
Rated discharge current: 20A
Battery input voltage range: 8-32V
Max. PV open circuit voltage:60V(at minimum operating environment temperature) 46V(at 25℃ environment temperature)
MPP voltage range:V(BAT)+2V～72V
Max. PV input power:260W(12V Battery) & 520W(24V battery)
Power terminals:#12 AWG(4mm2)
MT50 Remote Meter
This unit is compatible with Tracer A(N) , TRIRON N, Tracer BN, VSxxxxBN series controllers ONLY from EPsolar. And it's NOT compatible with RN series MPPT charge controller. Description MT-50, a new-generation remote display for EPEVER MPPT controllers is an associated display device which supports both the latest communication protocol and the voltage technology standard of mppt solar controllers.
Technical Data Faceplate dimension:98×98 mm / 3.86×3.86 inch Frame dimension:114×114 mm / 4.49×4.49 inch Connector type: RJ45 Meter cable:Standard 2m,Max 50m Ambient Temperature: -20°C -- +70°C/-4°F -- 158°F
SolarEpic 2206AN Solar Charge Controller 20A:
The controller adopts the three-stage charging mode, and
has perfect electronic protection function, which can
effectively extend the battery life, improve the system
performance, and ensure the system safety, stability and
long-term operation. TRIRION controller can be widely used
in RV, telecommunication base station, household system,
field monitoring, etc.
Product Features
• Advanced MPPT technology, with efficiency no less than 99.5%
• Monitor and set the parameters via mobile phone APP or PC software
• Advanced MPPT control algorithm to minimize the maximum power point loss rate and loss time
• Wide MPP operating voltage range
• High quality components, perfecting system performance, with maximum conversion efficiency of 98%
•Accurate recognition and tracking of multiple-peaks maximum power point
• International famous brands of ST and IR's components of high quality and low failure rate are used, which can ensure the product’s service life
• Charging power and current limitation function
• Compatible with lead-acid and lithium-ion batteries
Maximum Power Point Tracking Technology
Due to the nonlinear characteristics of solar array, there is a maximum energy output point (Max Power Point) on its curve. Traditional controllers, with switch charging technology and PWM charging technology, can’t charge the battery at the maximum power point, so can’t harvest the maximum energy available from PV array, but the solar charge controller with Maximum Power Point Tracking (MPPT) Technology can lock on the point to harvest the maximum energy and deliver it to the battery
The MPPT algorithm of our company continuously compares and adjusts the operating points to attempt to locate the maximum power point of the array. The tracking process is fully automatic and does not need user adjustment.
As the Figure 1-2, the curve is also the characteristic curve of the array, the MPPT technology will ‘boost’ the battery charge current through tracking the MPP. Assuming 100% conversion efficiency of the solar system, in that way, the following formula is established:
Product information
|
Item |
Tracer1206AN Tracer1210AN |
Tracer2206AN Tracer2210AN |
Tracer3210AN |
Tracer4210AN |
|||
|
Dimension |
172x139 x 44mm |
220x154x 52mm |
228x164x55mm |
252x180x63mm |
|||
|
Mounting dimension |
130x130mm |
170x145mm |
170x164mm |
210x171mm |
|||
|
Mounting hole size |
Φ5mm |
||||||
|
Terminal |
12AWG(4mm2) |
6AWG(16mm2) |
6AWG(16mm2) |
6AWG(16mm2) |
|||
|
Recommended cable |
12AWG(4mm2) |
10AWG(6mm2) |
8AWG(10mm2) |
6AWG(16mm2) |
|||
|
Weight |
0.57kg |
0.94kg |
1.26kg |
1.65kg |
|||
The MT series remote meter is an accessory which is compatible with the DuoRacer series controller. It can monitor the running data and working status of the controller via the remote meter. The remote meter can browse the controller’s parameters, set the battery typeand temperature unit, and clean the generated energy.It is suitable for RV, Camper, Boat, and so on.
Recommendations
- The MT11 is only allowed to connect with DR N series charge controller.Please confirm before purchase and installation.
- Pleasedo not install MT11 in a situation with strong electromagnetic
Features：
- Automatically identify and display the type,model and relevant parameterdata of controllers.
- Real-timedisplay the operational data and working status of the connected devices indigital,graphics and textual forms by a large-screen multifunction LCD.
- Three touch buttons are easy and quick to operate.
- No need for external power supply. Charge controller supply the power for MT11.
- It can browse the controller’s parameters, set the battery typeand temperatureunit, and clean the generated energy.
- Real-time display of failure information of the connecteddevices.
- Longer communication distance based on RS485.
Technical Specifications
|
Model |
MT11 |
|
Apply to model |
DRN series |
|
Self-consumption(Power on) |
13mA/5Vdc |
|
Self-consumption(Power off) |
4mA |
|
Communication way |
RS485 |
|
Communication port |
3.81-4P |
|
RS485 cable |
CC-RS485-RS485-3.81-4P-150(1.5m) CC-RS485-RS485-3.81-4P-500(5m) CC-RS485-RS485-3.81-4P-1000(10m) |
|
Environment temperature |
-20℃～+70℃ |
|
Storage temperature range |
-20℃～+70℃ |
|
Enclosure |
IP20 |
|
Dimension |
98.4×98.4mm |
|
Base cover dimension |
114×114mm |
|
Weight |
0.11kg |
Front View
LCD display screen
Man-machine interaction operation interface.
Buttons
The meter buttons include two function buttons and one switch button.
|
|
Press the button |
1.PV array parameters 2.Storage battery parameters 3.Browse the start battery parameters automatically ( |
|
|
Press the button |
Browse the PV array parameters Browse the Storage battery parameters Browse the start battery parameters |
|
Press the button and hold on 5s |
Temperature unitsBattery type |
|
|
|
Press the button |
The meter is powered ON |
|
Press the button and hold on 5s |
The meter is powered OFF |
)
Rear View
- RS485communicationport
It is used to connect the controller which Power the MT11.
- Communicationcable’s models
CC-RS485-RS485-3.81-4P-150(Included)
CC-RS485-RS485-3.81-4P-1000(Optional)
CC-RS485-RS485-3.81-4P-2000(Optional)
-
Pins definition
|
PIN |
Definition |
|
1 |
DC5V |
|
2 |
RS-485-B |
|
3 |
RS-485-A |
|
4 |
GND |
LCD display
|
Icon |
Instruction |
Icon |
Instruction |
|
|
BATT1 battery capacity level①0～12% |
|
BATT2battery capacity level①0～12% |
|
|
BATT1battery capacity level①13%～35% |
|
BATT2battery capacity level①13%～35% |
|
|
BATT1battery容量水平① 36％〜61％ |
|
BATT2battery capacity level①36%～61% |
|
|
BATT1battery capacity level①62%～86% |
|
BATT2battery capacity level①62%～86% |
|
|
BATT1battery capacity level① 87%～100% |
|
BATT2battery capacity level① 87%～100% |
|
|
Day |
|
PV array |
 |
Night |
|
BATT1 charging icon |
|
|
Display the parameters of PV |
|
BATT2charging icon |
|
|
Display the parameters of BATT1 |
|
BATT1temperature parameters |
|
|
Display the parameters of BATT2 |
|
AES signal icon |
|
|
Setting icon |
|
Battery type icon |
|
|
Auto global view sign |
|
Minimum voltage icon |
|
|
Fault Icon |
|
Maximum voltage icon |
①Battery power capacity is calculated by the linear relationship between the disconnect voltage of low voltage and float charging voltage.
EPEVER TRIRON N MPPT Solar Charge Controller
Based on common negative design and advanced MPPT control algorithm
MPPT Charge efficiency > 99%
This unit is compatible with Tracer A(N) , TRIRON N, Tracer BN, VSxxxxBN series controllers ONLY from EPsolar. And it's NOT compatible with RN series MPPT charge controller. Description MT-50, a new-generation remote display for EPEVER MPPT controllers is an associated display device which supports both the latest communication protocol and the voltage technology standard of mppt solar controllers.
Battery Temperature Sensor&Monitoring adapter
1. Remote Temperature Sensor
Model: RTS300R47K3.81A
Acquisition of battery temperature for undertaking
temperature compensation of control parameters
Length: 3 M
2. USB to RS485 Converter Adapter
Model: CC-USB-RS485-150U
The precision compression module and the overall locking (self release mechanical device) are designed to ensure that the quality of the press can be maintained in repeated compression.
Other info
|
Model |
H03 |
|
suitable object |
cable |
|
effect |
Break,tighten,strip,press
|
|
character |
general |
|
texture |
chisel tool steel |
|
style |
German-style |
