-4%
Out of stock

SHI series is a pure sine wave inverter which can convert 12/24/48Vdc to 220/230Vac 50/60Hz based on full digital and intelligent design.It features high reliability,high efficiency,concise outline,small volume,easy installation and operation.The inverter can be applied in many fields,such as household appliances,electric tools and industrial devices etc,especially for solar photovoltaic power system.

Feature:

  • Input & output fully isolation
  • Adoption of advanced SPWM technology, pure sine wave output
  • Dynamic current loop control technology
  • Wide DC input voltage range
  • Excellent EMC design
  • Low output harmonic distortion(THD≤3%)
  • LED indicators for input voltage range, load power range, normal output & failure state
  • Optional energy saving mode
  • Extensive electronic protection
Technical specifications:
Types SHI400-12 SHI400-22 SHI600-12 SHI600-22 SHI1000-22 SHI1000-42 SHI2000-22 SHI2000-42 SHI3000-22 SH 13000-42
Nominal Battery Voltage 12V 24V 12V 24V 24V 48V 24V 48V 24V 48V
Input Voltage Range 10.8~16Vdc 21.6~32Vdc 10.8~16Vdc 21.6~32Vdc 21.6~32Vdc 43.2~64Vdc 21.6~32Vdc 43.2~64Vdc 21.6~32Vdc 43.2 ~64Vdc
No Load Current <0.8A <0.45A <0.7A <0.45A <0.45A <0.35A <0.7A <0.7A <1.2A <1.0A
Output Wave Pure Sine Wave
Output Voltage 220Vac±3% /230Vac±10%
Continuous Power 400W 600W 1000W 2000W 3000W
Power 10 sec 600W 900W 1500W 3000W 4500W
Power 1.5 sec 800W 1200W 2000W 4000W 6000W
Surge Power 900W 1350W 2250W 4600W 6900W
Frequency 50/60Hz±0.2%
Distortion THD < 3% (resistive load)
Efficiency at Rated Power >91% >92% >91% >92% >93% >93.5% >93% >94% >93% >94%
Max. Efficiency >92% >93% >93% >94% >94% >94% >95% >95% >95% >95%
Terminal 16mm2 25mm2 25mm2 50mm2 50mm2
Dimensi ons 280Xl66X74.3mm 295 X186 X 82mm 295X208X98mm 436X249Xl16mm 507X249 % 116mm
Installatio n 150 X 158mm 150x178mm 150X200mm 236X220mm 236 X 270mm
Hole Size <P5mm <P6mm ①6mm ①6mm <P6mm
Net Weight 1.8kg 2.3kg 3.3kg 6.0kg 7.5kg
Working Temperature   -20℃~ +50℃
Storage Temperature  -35℃~ +70℃
Humidity <95%(N.C.)
Altitude < 5000m(Derating to operate according to IEC62040 at a height exceeding 1000m)
    $8.49
    Description

    This adapter is used to monitor each controller on the network using

    Solar Station PC software and update the firmware.
    this item include the two cables.
    1. Remote Temperature Sensor
    Model: RTS300R47K3.81A
    Acquisition of battery temperature for undertaking
    temperature compensation of control parameters
    Length: 3 M

    2. USB to RS485 Converter Adapter
    Model: CC-USB-RS485-150U



      Quick look
      -29%
      $20.00 $27.99

      Feature:

      Compatible with PC software & MT50 for real-time monitoring
      Connect to PC via USB interfaces with high compatibility
      Powered up by controller communication interface
      Record capacity: 20000 points(MAX)
      LED Indicator design, more intuitive display

      technical parameter

      Model

      eLOG01

      Input voltage

      410VDC

      Powered up by RS485 interface

      Average power consumption

      0.3W

      Baud rate

      115200

      Communication

      RS485

      Interface type

      2 RJ45

      1 Micro USB

      Record time

      10 minutes

      Dimensions

      71×67.62×25.8mm

      Mounting dimension

      57.6mm

      Mounting hole size

      Φ4.5

      Working temperature

      -2575

      Humidity

      5-95% (N.C.)

      Enclosure

      IP30

      Net weight

      42g

      Warranty

      2 years



        Quick look
        $82.96

        IPower series is a pure sine wave inverter which can convert 12/24/48Vdc into 110V/220Vac. It has the characteristics of concise outline, compact size, high reliability, high efficiency, easy to install and operate and so on. The inverter applicable to household emergency lighting system, vehicle mounted system and small field power supply, etc.

        Feature:

        • Safe design with input and output electrical isolation
        • Adoption of advanced SPWM technology, pure sine wave output
        • Optional output voltage220/230VAC (or 110/120VAC ), setted by DIP switch
        • Output frequency 50/60Hz, setted by DIP switch
        • LED indicators for working and fault status
        • Lower No-load consumption
        • Max. efficiency up to 95%
        • Input protection: Over voltage protection, low voltage protection
        • Output protection: Over load protection, short circuit protection
        • Over temperature protection: Temperature-controlled Fan Ventilation; Inverter turns off automatically
        • Industrial grade design
        Technical specifications(350W/500W):
                      Model 350-11 500-11 350-21 500-21 350-12 500-12 350-22 500-22
        Item
        Input Rated Voltage 12VDC 24VDC 12VDC 24VDC
        Input Voltage Range 10.8~16VDC 21.6~32VDC 10.8~16VDC 21.6~32VDC
        Input surge voltage <32V <44V <32V <44V
        Fuse 32VDC/50A 2*32VDC/35A 32VDC/30A 2*32VDC/25A 32VDC/50A 2*32VDC/35A 32VDC/30A 2*32VDC/25A
        No-load current <0.7A <0.9A <0.5A <0.5A <0.7A <0.9A <0.5A <0.5A
        Output Voltage 110VAC(±5%) 220VAC(±5%)
        120VAC(-10%~+5%) 230VAC(-10%~+5%)
        Output Continuous Power(-20℃~+45℃) 350VA 500VA 350VA 500VA 350VA 500VA 350VA 500VA
        Power factor 0.8 0.8
        Instantaneous impact power ≥750VA ≥1000VA ≥750VA ≥1000VA ≥750VA ≥1000VA ≥750VA ≥1000VA
        Output way Single phase Single phase
        Output Wave Pure sine wave Pure sine wave
        Output Frequency 50/60Hz(±0.2%) 50/60Hz(±0.2%)
        Distortion THD THD≤5%(Resistive load) THD≤5%(Resistive load)
        Max. Efficiency 91% 92%
        90%(IP350-11) 91%(IP350-12)
        Max. USB Output 5VDC/1A 5VDC/1A



        Model 350-11
        350-12
        350-21
        350-22
        500-11
        500-12
        500-21
        500-22
        DC input terminal 6mm2
        Overall dimension 214×105.5×57.7mm 232.2×132×74.5mm
        Mounting dimension 185.5×76.7mm 205×102mm
        Mounting hole size Φ4.2mm Φ5.2mm
        Net weight 0.9kg 1.4kg
        Working environment temperature -20℃~+45℃
        Storage temperature range -35℃~+70℃
        Humidity range ≤93%(N.C.)
        Enclosure IP20
        Altitude <2000m
        (Derating to operate according to IEC62040 at a height exceeding 1000 m)
        Technical specifications(1500W/2000W):
        Model  1500-11 1500-21 2000-21 2000-41 1500-12 1500-22 2000-22 2000-42
        Item
        Input Rated Voltage 12VDC 24VDC 24VDC 48VDC 12VDC 24VDC 24VDC 48VDC
        Input Voltage Range 10.8~16VDC 21.6~32VDC 21.6~32VDC 43.2~60VDC 10.8~16VDC 21.6~32VDC 21.6~32VDC 43.2~60VDC
        Input surge voltage <20VDC <40VDC <40VDC <80VDC <20VDC <40VDC <40VDC <80VDC
        No-load current <1.0A <0.6A <0.6A <0.4A <1.0A <0.6A <0.6A <0.4A
        Output Voltage 110VAC(±5%) 110VAC(±5%) 220VAC(±5%) 220VAC(±5%)
        120VAC(-7%~+5%) 120VAC(-10%~+5%) 230VAC(-7%~+5%) 230VAC(-10%~+5%)
        Output Continuous Power 1200W 1600W 1200W 1600W
        Output Power 15 min. 1500W 2000W 1500W 2000W
        Instantaneous impact power 2400W 3200W 2400W 3200W
        Output way Single phase Single phase Single phase Single phase
        Output Wave Pure sine wave Pure sine wave Pure sine wave Pure sine wave
        Output Frequency 50/60Hz(±0.2%) 50/60Hz(±0.2%) 50/60Hz(±0.2%) 50/60Hz(±0.2%)
        Distortion THD THD≤5%(Resistive load) THD≤5%(Resistive load) THD≤5%(Resistive load) THD≤5%(Resistive load)
        Max. Efficiency 93% 94% 95% 93% 94% 95%
        Max. USB Output 5VDC/1A 5VDC/1A 5VDC/1A 5VDC/1A
        Binding post Φ10mm Φ10mm Φ10mm Φ10mm



        Model  1500-11
        1500-12
        1500-21
        1500-22
        2000-21
        2000-22
        2000-41
        2000-42
        Item
        Overall dimension 326.12×231.5×98.5mm 284.7×231.5×98.5mm 326.12×231.5×98.5mm
        Mounting dimension 208×220mm 163×220mm 208×219.5mm
        Mounting hole size Φ5.5mm Φ5.5mm
        Net weight 3.9kg 4.0kg



        Working Temperature -20℃~+45℃
        Storage Temperature -35℃~ +70℃
        Humidity < 95%(N.C.)
        Enclosure IP20
        Altitude < 5000 m (Derating to operate according to IEC62040 at a height exceeding 1000 m)
          $26.96

          Note : just can be use for ANDROID phone,

          CAN'T be use for iPHONE.

          APK Download:Epever(WIFI&BLE)

          Feature:

               eBox-BLE-01
          • Realize wireless monitoring function of solar controller and inverter
          • Support mobile phone APP, plug and play, simple and convenient to set
          • Use high performance, ultra-low power consumption Bluetooth dedicated chip
          • Adopt Bluetooth 4.0 and BLE technology
          • Fast communication, strong anti-interference ability
          • No need of external power supply
          • Communication distance up to 10 m
          • Master reset adapter

          Bluetooth

              eBox-WIFI-01

          •  Realize wireless monitoring function of solar controller and inverter
          • Support mobile phone APP, plug and play, simple and convenient to set
          • Use high performance CPU with core M4
          • Ultra-low power consumption and high speed data processing capability
          • No need of external power supply
          • Communication distance up to 50 m
          • One-key restore the factory settings

          WIFI



          Technical Specifications

          Model→

          Item↓

          eBox-BLE-01

          eBox-WIFI-01

          Input Voltage

          5VDC

          (Direct powered by RS485 port )

          5VDC

          (Direct powered by RS485 port )

          Standby power

          Consumption

          0.04W

          0.20W

          Operation power

          consumption

          0.05W

          0.25W

          Communication distance

          ≤10m

          ≤50m

          Port baud rate

          300bps~230400bps (Default115200)

          300bps~230400bps (Default 115200)

          Communication

          RS485 to BLE

          RS485 to WIFI

          Interface type

          RJ45

          RJ45

          Connecting cable

          Standard network cable

          (Parallel cable)

          Standard network cable

          (Parallel cable)

          Overall dimension

          51*67*24.5mm

          51*67*24.5mm

          Mounting dimension

          41.2mm

          41.2mm

          Mounting hole size

          Φ3.2mm

          Φ3.2mm

          Working temperatur

          -20~70℃

          -35~75℃

          Enclosure

          IP30

          IP30

          Net weight

          37g

          39g

            -36%
            Out of stock

            Feature

              • Ultra-saving pliers. Cold press pliers. Terminal pliers series
              • The new crimping pliers adopts the principle of lever to effectively design the handle.
              • Although the structure is small and compact, it is very labor-saving when operating, especially when crimping the wires with large transverse joint sections.
              • For non-welded, electrical connections that meet the accuracy criteria
              • Precision crimping module and integral locking (custom release mechanism) design ensures high quality crimp line standards during repeated crimping
              • Precise and accurate adjustment before leaving the factory.





            Model

            H03

            suitable object

            cable

            effect



            Break,tighten,strip,press



            character

            general

            texture

            chisel tool steel

            style

            German-style

              $109.00

              DuoRacer Series ——MPPT Dual Battery Solar Charge Controller

              DuoRacer MPPT charge controller is made for charging two batteries (shown as BATT1 and BATT2 below) at the same time in a solar system. This controller supports multiple life battery (BATT1) types, including Sealed, Gel, Flooded, LiFePO4, and Li-NiCoMn, which is suitable for RV, Camper, Boat, and so on. The device recognizes the start battery (BATT2) system voltage automatically, and trickle charges the battery when the conditions are satisfied.

              The controller adopts the advanced MPPT control algorithm,which will minimize the maximum power point loss rate and loss time,also fast track the maximum power point(MPP) of the PV array, and obtain the maximum energy from solar array under any conditions. The energy utilization in the MPPT solar system is increased by 20-30% compared with PWM charging method. When there is no manual operation for a long time, and the charging conditions cannot be reached, the controller will turn to low-power mode, which reduces the loss and battery power waste to enhance the products life. The system parameters are shown and set by LED/LCD or the MT11 remote meter (Accessory).

              The AES control signal of the car refrigerator is built in the controller, which will supply the surplus solar power to the refrigerator to avoid energy waste. The controller comes with IP33 protection level, which is waterproof and dustproof. Multiple protection features, including battery overcharge protection, over discharge protection, and reverse connection protection of the PV and battery, which effectively ensure the solar system safety, stability, and lifetime.





              Features:

              · Maximum Power Point Tracking technology with ultra-fast tracking speed and the tracking efficiency is no less than 99.5% guaranteed
              · Advanced MPPT control algorithm to minimize the MPPlost rate and lost time
              · The wider range of the MPP operation voltage to improve the PV module
                 utilization
              · Auto control function of charging power & charging current limitation(BATT1)
              · High quality and low failure rate components of ST, TI and Infineon to ensure      the product life
              · Digital circuit control of adaptive three-stage charging mode to enhance BATT1
                 life.
              · BATT1 type can be set via LED/LCD.
              · Product runs into the low-power mode when there is no manual operation for a
                long time, and charging conditions are not satisfied (PV<5V).
              · 100% charging and discharging in operationenvironmental temperature range.
              · LED and LCD dispiay units selectable.
              · AES control signal for car refrigerator to avoid energy waste.
              · Standard Modbus protocol, and RS485 (5V/200mA) communication port for         the customer to expand the application area.





              Technical specifications

              Item

                   DR1206N-DDB      DR1206N-DDS

              DR2210N-DDB DR2210N-DDS

              DR3210N-DDB DR3210N-DDS

              BATT1 rated voltage

              12/24VDC

              Rated Charge Current

              10A

              20A

              30A

              Battery Input Voltage Range

              8.5~32V

              Max. PV Open Circuit Voltage

              60V(At min. operating environment temp.) 46V(At 25℃ environment temp.)

              100V(At min. operating environment temp.) 92V(At 25℃ environment temp.)

              MPP Voltage Range

              (Battery Voltage+2V)~36V

              (Battery Voltage+2V)~72V

              Rated Charge Power

              130W/12V

              260W/24V

              260W/12V 520W/24V

              390W/12V 780W/24V

              Max. conversion efficiency

              97.40%

              97.50%

              98%

              Full load efficiency

              97%

              96%

              96%

              Self-consumption

              12mA/12V;8mA/24V 4mA/12V;3mA/24V(Low-power mode)

              26mA/12V;15mA/24V 19mA/12V;10mA/24V(Low-power mode)

              Temperature compensate coefficient①

              -3mV/℃/2V(default)

              Grounding

              Common negative

              Common negative

              13.8V/12V;27.6V/24V(default)

              BATT2 Charge return voltage

              13V/12V;26V/24V(defaul

              AES signal port ②

              5VDC/Max.200mA(3.81-4P)

              RS485 com. port ②

              Com. baud rate③

              115200(default)

              LCD backlight time④

              60S(default)

               Mechanical Parameters



              Item

              DR1206N-DDB DR1206N-DDS

              DR2210N-DDB DR2210N-DDS

              DR3210N-DDB DR3210N-DDS

              Dimension

              227.2×143×58.1mm

              243.7×158×63mm

              247.2×165×68.5mm

              Mounting dimension

              160×134mm

              180×149mm

              180×156mm

              Mounting hole size

              φ5mm

              Terminal

              12AWG/4mm2 (BATT1) 12AWG/4mm²(BATT2)

              6AWG/16mm2 (BATT1)

              12AWG/4mm²(BATT2)

              Recommended cable size

              12AWG/4mm²(BATT1) 12AWG/4mm²(BATT2)

              10AWG/6mm²(BATT1) 12AWG/4mm²(BATT2)

              8AWG/6mm²(BATT1) 12AWG/4mm²(BATT2)

              Weight

              0.8kg

              1.1kg

              1.4kg



               Environmental Parameters



              Item

              DR1206/2210N-DDB DR1206/2210N-DDS

                DR3210N-DDB   DR3210N-DDS

              Working environment temperature(100% input and output)

              ﹣20℃~+50℃(DDS)

              ﹣30℃~+50℃(DDB

              ﹣20℃~+45℃(DDS)

              ﹣30℃~+45℃(DDB)

              Storage temperature range

              -30℃~+80℃

              Relative humidity

              ≤95%, N.C

              Enclosure

              IP33 3-protection against solid objects: protected against solids objects over 2.5mm. 3-protected against sprays to 60°from the vertical.

              Pollution degree

              PD2



              ①The Temperature compensate coefficient is zero and not changeable when the life battery type is lithium battery。

              ②If the AES signal port and RS485 communication port are used in the same time, the toal current is no greater than 200mA.

              ③The communication baud rate can only be set via PC software.

              ④The LCD backing time can only be set via PC software, setting range is 0~999S and the 0s means the LCD is on all the time. DDB:DuoRacer Display Basic (LED) DDS:DuoRacer Display Standard (LCD)



               VIDEO DEMO

              GOFor more product video please click here


                $35.00

                The MT series remote meter is an accessory which is compatible with the DuoRacer series controller. It can monitor the running data and working status of the controller via the remote meter. The remote meter can browse the controller’s parameters, set the battery typeand temperature unit, and clean the generated energy.It is suitable for RV, Camper, Boat, and so on.

                Recommendations

                • The MT11 is only allowed to connect with DR N series charge controller.Please confirm before purchase and installation.
                • Pleasedo not install MT11 in a situation with strong electromagnetic

                Features

                • Automatically identify and display the type,model and relevant parameterdata of controllers.
                • Real-timedisplay the operational data and working status of the connected devices indigital,graphics and textual forms by a large-screen multifunction LCD.
                • Three touch buttons are easy and quick to operate.
                • No need for external power supply. Charge controller supply the power for MT11.
                • It can browse the controller’s parameters, set the battery typeand temperatureunit, and clean the generated energy.
                • Real-time display of failure information of the connecteddevices.
                • Longer communication distance based on RS485.

                Technical Specifications

                Model

                MT11

                Apply to model

                DRN series

                Self-consumption(Power on)

                13mA/5Vdc

                Self-consumption(Power off)

                4mA

                Communication way

                RS485

                Communication port

                3.81-4P

                RS485 cable

                CC-RS485-RS485-3.81-4P-150(1.5m)

                CC-RS485-RS485-3.81-4P-500(5m)

                CC-RS485-RS485-3.81-4P-1000(10m)

                Environment temperature

                -20℃~+70℃

                Storage temperature range

                -20℃~+70℃

                Enclosure

                IP20

                Dimension

                98.4×98.4mm

                Base cover dimension

                114×114mm

                Weight

                0.11kg


                Front View




                LCD display screen

                Man-machine interaction operation interface.

                Buttons

                The meter buttons include two function buttons and one switch button.



                Press the button

                1.PV array parameters

                2.Storage battery parameters

                3.Browse the start battery parameters automatically ()



                Press the button

                Browse the PV array parameters

                Browse the Storage battery parameters

                Browse the start battery parameters

                Press the button and hold on 5s

                Temperature unitsBattery type



                Press the button

                The meter is powered ON

                Press the button and hold on 5s

                The meter is powered OFF



                 Rear View





                • RS485communicationport

                It is used to connect the controller which Power the MT11.

                • Communicationcables models

                CC-RS485-RS485-3.81-4P-150(Included)

                CC-RS485-RS485-3.81-4P-1000(Optional)

                CC-RS485-RS485-3.81-4P-2000(Optional)



                • Pins definition

                PIN

                Definition

                1

                DC5V

                2

                RS-485-B

                3

                RS-485-A

                4

                GND


                LCD
                 display



                Icon

                Instruction

                Icon

                Instruction



                BATT1 battery capacity level0~12%



                BATT2battery capacity level0~12%



                BATT1battery capacity level13%~35%



                BATT2battery capacity level13%~35%



                BATT1battery容量水平 36%〜61%



                BATT2battery capacity level36%~61%



                BATT1battery capacity level62%~86%



                BATT2battery capacity level62%~86%



                BATT1battery capacity level

                87%~100%



                BATT2battery capacity level

                87%~100%



                Day



                PV array

                Night



                BATT1 charging icon



                Display the parameters of PV



                BATT2charging icon



                Display the parameters of BATT1



                BATT1temperature parameters



                Display the parameters of BATT2



                AES signal icon



                Setting icon



                Battery type icon



                Auto global view sign



                Minimum voltage icon



                Fault Icon



                Maximum voltage icon

                Battery power capacity is calculated by the linear relationship between the disconnect voltage of low voltage and float charging voltage.

                  Quick look

                  Search

                  Just added to your cart:
                  Qty:
                  Total:
                  Subtotal:
                  Excl. postage
                  My Bag
                  Just added to your wishlist:
                  Excl. postage
                  My Wishlist

                  Join Our Mailing List

                  Spin to win Spinner icon
