SolarEpic65 Products
EPIPDB-COM, 20A, 12/24V auto-work
NOTES: For use with solar panels only
Dual battery solar controller For RVs, Caravans, and boats
This solar controller can charge two battery banks. No load terminals
Features:
·Two battery charging eliminates the extra cost of two separate solar charging system
·Intelligent System Optimum Control
·12/24V auto work
·Battery type selection
·Charging frequency optional
·High efficient Series PWM charging
·Local external temperature compensation
·Remote temperature sensor optional
·Use MOSFET as electronic switch, without any mechanical switch
·Remote meter MT-1 optional
·Electronic protection: over charging, short circuit, battery reverse polarity protection
·Microcontroller digital accuracy
see detalied on PC
- 【High PV Input Power】This 60 amp MPPT Solar Panel Charger works with 840W Solar Panel on 12V Battery System and 1680W on 24V Battery.
- 【Compatible with a variety of batteries】Negative grounding design, four load control modes, supports lead-acid and lithium batteries.
- 【Powerful electronic protections】Eight electronic protections, including reverse polarity protection(for battery and array), solar short circuit protection, over-temperature protection, load short circuit protection, load over-current protection, heat sink temperature limit protection, over-volt / low-volt protection and battery shedding protection.
- 【OLED screen and MH-M80 Meter】The controller has a 1.3 inches OLED screen and a function button. MH-M80 Meter was attached, which can display system operating information and error indications. In addition to that, 3 status LEDs provide system status at a glance. The meter can easily set the parameters of the controller.
- 【4-stage battery charging】4-stage battery charging algorithm for rapid, efficient, and safe battery charging. The maximal wire size of the controller is 3AWG(25mm2).
Product Description
- Charging status / Load output status / Error LED
- Function button
- Digital OLED display
- Temperature sensor terminals
- Dual RJ45 serial communication ports
- Input and output terminals (PV+/PV-/BAT+/BAT-/LOAD+/LOAD-)
- Dedicated for grounding wire
- Reverse fixing hole
- Mounting holes for positively fixed fittings
- Terminal cover plate
|
|
|
|
|---|---|---|
SolarEpic NS24H60 Solar Charge Controller 60A:Built with advanced power tracking technology to optimize the working of your solar charger system. The controller features a smart tracking algorithm that maximizes the energy from the solar PV module(s) and charges the battery. It supports lead-acid and lithium batteries. |
MH-M80 Remote Meter:The digital Remote Meter displays system operating information, error indications. Information is displayed on an OLED display. Additionally, 3 status LEDs provide system status at a glance. The Meter can easily set the parameters of the controller. It can be flush mounted in a wall or surface mounted using the mounting frame(included). The MH-M80 is supplied with 3.3 ft (1.0 m) of cable(Can be extended), a mounting frame, and mounting screws. The MH-M80 connects to the RJ-45 port on the MPPT controller. |
Remote Temperature Sensor:It is used to sense the environment's temperature. If the remote temperature sensor is not connected to the controller, the default setting for battery charging or discharging temperature is 25 °C without temperature compensation. Put this sensor near the battery. |
Description
- 100V PV Input & Compatiby with 12/24V Battery System
- Support 4 charging options: Sealed, Gel, Flooded and User.
- Wide MPP operating voltage range
- Maximum DC/DC transfer efficiency as high as 98.7%
- 100% Genuine MPPT
Product Description
SolarEpic 60A MPPT Solar Charge Controller EM2460 100V PV
Product information
| Package Dimensions | 13.78 x 10.24 x 5.12 inches |
|---|---|
| Item Weight | 6.56 pounds |
| Manufacturer | iPanda |
| ASIN | B088TNY3XW |
| Item model number | EM2460 |
Videos
（For more product video please click here）
User's Manual
Epever MPPT Solar Charge Controller Battery Charger Regulator Tracer AN Series Max Input 100V
Features：
• Advanced MPPT technology, with efficiency no less than 99.5%
• Ultra-fast tracking speed and guaranteed tracking efficiency
• Advanced MPPT control algorithm to minimize the maximum power point loss rate and loss time
• Wide MPP operating voltage range
• High quality components, perfecting system performance, with maximum conversion efficiency of 98%
• Accurate recognition and tracking of multiple-peaks maximum power point
• International famous brands of ST and IR's components of high quality and low failure rate are used, which can ensure the product’s service life
• Charging power and current limitation function
• Compatible with lead-acid and lithium-ion batteries
• Battery temperature compensation function
• Real-time energy statistics function
• Overheating power reduction function
• Multiple load work modes
• The communication port adopts professional protection chip, which can provide 5VDC power supply, and has over-current and short-circuit protection.
• With RS-485 communication bus interface and Modbus communication protocol, it is available to meet various communication requirements in different situations.
• Monitor and set the parameters via mobile phone APP or PC software
• Full-load operation without any drop in capacity within the range of working environment temperature
• Extensive electronic protection
Electrical Parameters
|
Item |
Tracer 1210AN |
Tracer 2210AN |
Tracer 3210AN |
Tracer 4210AN |
|
System nominal voltage |
12/24VDC① Auto |
|||
|
Rated charge current |
10A |
20A |
30A |
40A |
|
Rated discharge current |
10A |
20A |
30A |
40A |
|
Battery voltage range |
8~32V | |||
|
Max. PV open circuit voltage |
100V② 92V③ |
|||
|
MPP voltage range |
(Battery voltage +2V)～72V |
|||
|
Max. PV input power |
130W/12V 260W/24V |
260W/12V 520W/24V |
390W/12V 780W/24V |
520W/12V 1040W/24V |
|
Self-consumption |
≤12mA | |||
|
Discharge circuit voltage drop |
≤0.23V | |||
|
Temperature compensate coefficient④ |
-3mV/℃/2V (Default) | |||
|
Grounding |
Common negative | |||
|
RS485 interface |
5VDC/100mA | |||
|
LCD backlight time |
60S (Default) | |||
①When a lead-acid battery is used, the controller hasn’t the low temperature protection.
②At minimum operating environment temperature
③At 25℃ environment temperature
④When a lithium-ion battery is used, the system voltage can’t be identified automatically.
Mechanical Parameters
|
Item |
Tracer1210AN |
Tracer2210AN |
Tracer3210AN |
Tracer4210AN |
|||
|
Dimension |
172x139 x 44mm |
220x154x 52mm |
228x164x55mm |
252x180x63mm |
|||
|
Mounting dimension |
130x130mm |
170x145mm |
170x164mm |
210x171mm |
|||
|
Mounting hole size |
Φ5mm |
||||||
|
Weight |
0.57kg |
0.94kg |
1.26kg |
1.65kg |
|||
User's Manual
Epever MPPT Solar Charge Controller Battery Charger Regulator Tracer AN Series Max Input 150V /200V
Tracer-AN series controller, based on multiphase synchronous rectification technology (MSRT) and advanced MPPT control algorithm, with dual-core processor architecture and common negative design, has the features of high response speed, high reliability and high industrial standard. MSRT can guarantee very high conversion efficiency in any charge power, which sharply improves the energy efficiency of solar system; Advanced MPPT control algorithm minimize the maximum power point loss rate and loss time, to ensure the tracking efficiency, corresponding speed as well as high conversion efficiency under high or low power, so that in any situation, Tracer-AN products can rapidly track the maximum power point(MPP) of PV array to obtain the maximum energy of the panel. The limitation function of the charging power and current, and automatic power reduction function fully ensure the stability when works with oversize PV modules and operate under high temperature environment.
Features:
- High quality and low failure rate components of ST and IR ensure the product’s service life
- 100% charging and discharging in working environment temperature range
- Maximum DC/DC transfer efficiency as high as 98.7%
- Advanced MPPT technology & ultra-fast tracking speed guarantee tracking up to 99.5%
- Advanced MPPT control algorithm minimize the MPP loss rate and loss time
- Accurate recognition and tracking of multiple-peaks maximum power point
- Wide MPP operating voltage range
- Limit the charging power and current over rated value
- Support 4 charging options: Sealed, Gel, Flooded and User.
- Battery temperature compensation function
- Real-time energy statistics function
- Automatic over-temperature power reduction function
- Load relay control to realize diversified load work modes
- Auto-control of utility and generator relay design
- Remote temperature sensor and remote voltage sensor design, collect more accurate data of battery temperature and voltage value
- Isolated RS-485 with 5VDC/200Ma protected output for no power devices, with MODBUS protocol
- Monitor and set the parameters via mobile phone APP or PC software
Parameters
User's Manual
Description
20A EPEVER Tracer 2206AN MPPT Solar Charge Controller
Based on common negative design and advanced MPPT control algorithm
MPPT Charge efficiency > 99%
Technical Data: Nominal system voltage:12/24VDC auto work
Rated charge current :20A
Rated discharge current: 20A
Battery input voltage range: 8-32V
Max. PV open circuit voltage:60V(at minimum operating environment temperature) 46V(at 25℃ environment temperature)
MPP voltage range:V(BAT)+2V～72V
Max. PV input power:260W(12V Battery) & 520W(24V battery)
Power terminals:#12 AWG(4mm2)
MT50 Remote Meter
This unit is compatible with Tracer A(N) , TRIRON N, Tracer BN, VSxxxxBN series controllers ONLY from EPsolar. And it's NOT compatible with RN series MPPT charge controller. Description MT-50, a new-generation remote display for EPEVER MPPT controllers is an associated display device which supports both the latest communication protocol and the voltage technology standard of mppt solar controllers.
Technical Data Faceplate dimension:98×98 mm / 3.86×3.86 inch Frame dimension:114×114 mm / 4.49×4.49 inch Connector type: RJ45 Meter cable:Standard 2m,Max 50m Ambient Temperature: -20°C -- +70°C/-4°F -- 158°F
SolarEpic 2206AN Solar Charge Controller 20A:
The controller adopts the three-stage charging mode, and
has perfect electronic protection function, which can
effectively extend the battery life, improve the system
performance, and ensure the system safety, stability and
long-term operation. TRIRION controller can be widely used
in RV, telecommunication base station, household system,
field monitoring, etc.
Product Features
• Advanced MPPT technology, with efficiency no less than 99.5%
• Monitor and set the parameters via mobile phone APP or PC software
• Advanced MPPT control algorithm to minimize the maximum power point loss rate and loss time
• Wide MPP operating voltage range
• High quality components, perfecting system performance, with maximum conversion efficiency of 98%
•Accurate recognition and tracking of multiple-peaks maximum power point
• International famous brands of ST and IR's components of high quality and low failure rate are used, which can ensure the product’s service life
• Charging power and current limitation function
• Compatible with lead-acid and lithium-ion batteries
Maximum Power Point Tracking Technology
Due to the nonlinear characteristics of solar array, there is a maximum energy output point (Max Power Point) on its curve. Traditional controllers, with switch charging technology and PWM charging technology, can’t charge the battery at the maximum power point, so can’t harvest the maximum energy available from PV array, but the solar charge controller with Maximum Power Point Tracking (MPPT) Technology can lock on the point to harvest the maximum energy and deliver it to the battery
The MPPT algorithm of our company continuously compares and adjusts the operating points to attempt to locate the maximum power point of the array. The tracking process is fully automatic and does not need user adjustment.
As the Figure 1-2, the curve is also the characteristic curve of the array, the MPPT technology will ‘boost’ the battery charge current through tracking the MPP. Assuming 100% conversion efficiency of the solar system, in that way, the following formula is established:
Product information
|
Item |
Tracer1206AN Tracer1210AN |
Tracer2206AN Tracer2210AN |
Tracer3210AN |
Tracer4210AN |
|||
|
Dimension |
172x139 x 44mm |
220x154x 52mm |
228x164x55mm |
252x180x63mm |
|||
|
Mounting dimension |
130x130mm |
170x145mm |
170x164mm |
210x171mm |
|||
|
Mounting hole size |
Φ5mm |
||||||
|
Terminal |
12AWG(4mm2) |
6AWG(16mm2) |
6AWG(16mm2) |
6AWG(16mm2) |
|||
|
Recommended cable |
12AWG(4mm2) |
10AWG(6mm2) |
8AWG(10mm2) |
6AWG(16mm2) |
|||
|
Weight |
0.57kg |
0.94kg |
1.26kg |
1.65kg |
|||
